Onsrud 5-axis CNC router
25 HP spindle; 5-axis
10 ft × 30 ft table
3-, 4- & 5-Axis · 10 × 30 ft Router · CNC Turning
Machining
CNC milling, large-format routing, and turning for components and critical features on fabricated assemblies.
View equipment detailsOVERVIEW
Equipment and working range
3-, 4-, and 5-axis machining spans large-format routing, vertical machining centers, and CNC turning. Review the listed travels and capacities alongside your part geometry, workholding, material, and inspection requirements.
Axes3-, 4-, and 5-axis
Router Table10 ft × 30 ft
Largest VMC Travel60 × 26 × 25.6 in
TurningUp to 16.8 in diameter × 61.4 in length
MaterialsAluminum, stainless steel, titanium, Inconel, tool steel; review other materials with our team
PROCESS DETAILS
Equipment & process details
Mori Seiki MV653 VMC
25 HP; 6,000 RPM
60 × 26 × 25.6 in travel
Bridgeport VMC-760
6,000 RPM
31.5 × 20 × 19.7 in travel
Mori Seiki SL-303 long bed
35–2,500 RPM; 3.5 in bar capacity
16.8 in diameter × 61.4 in turning length
Methods Slant 50
35–3,500 RPM; 2.56 in bar capacity
10.2 in diameter × 20.9 in turning length
Planning your machining project?
Source machined components on their own or include them in a fabricated and finished assembly, with mating features reviewed together.
Workholding, tool access, feature depth, and material affect feasible tolerances and setup. Published travels and turning capacity are equipment references; the part envelope is reviewed separately.
Plan your complete manufacturing packageInclude with your request
- Dimensioned drawing and 3D model, revision, material grade, and stock condition
- Datum scheme, critical tolerances, threads, surface finish, and inspection requirements
- Prototype or production quantities, repeat demand, and downstream assembly needs
For controlled technical data, arrange the appropriate transfer with our team before sending it.
